5.0W High Quality Factory Wholesale Customized Thermal Pad Thermal Gap Filler Insulation Sheet Silicone Pad For LED CPU GPU MOS

Ampliación de imagen : 5.0W High Quality Factory Wholesale Customized Thermal Pad Thermal Gap Filler Insulation Sheet Silicone Pad For LED CPU GPU MOS

Datos del producto:

Lugar de origen:	PORCELANA
Nombre de la marca:	ZIITEK
Certificación:	UL and RoHs
Número de modelo:	TIF800US

Pago y Envío Términos:

Cantidad de orden mínima:	1000pcs
Precio:	Negociable
Detalles de empaquetado:	1000pcs/bolsa
Tiempo de entrega:	3-5 días de trabajo
Capacidad de la fuente:	10000/día

Contacto

Descripción detallada del producto

Nombre del producto:	5.0W Fábrica de alta calidad Almohadilla térmica personalizada Termal BACH Termal Fliller Aislamient	Palabras clave:	cojín termal del reemisor de isofrecuencia
Conductividad térmica:	5,0 W/m-K	Construcción y Composición:	Elastómero de silicona lleno de cerámica
Muestra:	Gratis	Densidad:	3.4 g/cm³
Dureza:	20 orilla 00	Espesor:	Disponible adentro varía Thicknes
Solicitud:	MOS de la CPU LED y de la GPU

5.0W High Quality Factory Wholesale Customized Thermal Pad Thermal Gap Filler Insulation Sheet Silicone Pad For LED CPU GPU MOS

Products description

The TIF^®800US thermally conductive interface materials are applied to fill the air gaps between the heating elements and the heat dissipation fins or the metal base. Their flexibility and elasticity make them suited to the coating of the very uneven surfaces. Heat can transmit to the metal housing or dissipation plate from the separate elements or even the entire PCB, which in effect enhances the efficiency and life-time of the heat-generating electronic components.

Features:

> Good thermal conductive: 5.0W/mK
> Naturally tacky needing no further adhesive coating
> Soft and Compressible for low stress applications
> Available in varies thickness

> Broad range of hardnesses available
> Moldability for complex parts
> Outstanding thermal performance

Applications:

> Cooling components to the chassis of frame
> High speed mass storage drives
> Heat Sinking Housing at LED-lit BLU in LCD
> LED TV and LED-lit lamps
> RDRAM memory modules
> Micro heat pipe thermal solutions
> Handheld portable electronics
> Semiconductor automated test equipment (ATE)
> CPU
> Display card
> Mainboard/mother board
> Notebook

Typical Properties of TIF^®800US Series
Color	Gray	Visual
Construction & Compostion	Ceramic filled silicone elastomer	******
Specific Gravity	3.4g/cc	ASTM D297
Thickness range	0.020"(0.500)~0.200"(5.0mm)	ASTM D374
Hardness	20 Shore 00	ASTM 2240
Operating temp	-40 to 200℃	******
Dielectric Breakdown Voltage	≥5000 VAC	ASTM D149
Dielectric Constant @1MHz	4.5	ASTM D150
Volume Resistivity	≥ 1.0X10¹² Ohm-meter	ASTM D257
Flame rating	94 V0	UL E331100
Outgassing (TML)	0.55%	ASTM E595
Thermal conductivity	5.0 W/m-K	ASTM D5470
Thermal conductivity	5.0 W/m-K	ISO 22007-2

Products specification

Product Thicknesses: 0.020-inch to 0.200-inch (0.5mm to 5.0mm) with increments of 0.01 inch(0.25mm).

Product Sizes: 8" x 16"(203mm x406mm)Component Codes:
Reinforcement Fabric: FG (Fiberglass).
Coating Options: NS1 (Non-adhesive treatment), DC1 (Single-sided hardening).
Adhesive Options: A1/A2 (Single-sided/Double-sided adhesive).
The TIF series is available in custom shapes and various forms. For other thicknesses or more information, please contact us.

Company Profile

Ziitek Electronic Material and Technology Ltd. is a R&D and production company, we have many production lines and processing technology of thermal conductive materials, owns advanced production equipment and optimized process, can provide various thermal solutions for different applications.

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China.

Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra cost?

A: Yes, we could offer samples free of charge.
